AGC10R - 10A 250V 1/4X1-1/4 Rohs Fa Glass Fuse

Eaton

$1.69 (Each)
$1.69 (Each)
$8.45 (Per 5)

Availability: In Stock Locally

Buy Now

QTY:

Each

Overview
Specifications
Current Stock
Alternate Items

Overview

Thank you for your suggestions! We appreciate your assistance in improving our software. It helps us serve you even better!

Edit Mode: Please login to suggest improvements for this item.

Close

Help Improve Our Data

Quick Specs

Catalog Number: AGC10R Vendor Code BUS
Manufacturer: Eaton
Manufacturer's Part Number: AGC-10-R
Description: 10A 250V 1/4X1-1/4 Rohs Fa Glass Fuse
Fuse, Fast Acting Fuse Speed, 120/3.6K S Response Time, Ferrule End X Ferrule End Connection, 10 A, 250 V Ac, Glass (Body);Brass( End Cap) Material, Ferrule Terminal, 1/4 In Diameter, 1-1/4 In Overall Length, 0.01 LB
Slang Terms: Suggest a New Term
Categories: Fuses - Small Dimension Fuses Mark as Incorrect
Suggest a New Category
Classification: Glass Fuses (and Ceramic)
UNSPSC: 39121607 - Glass body fuses
UPC/GTIN: 051712654982 / 00051712654982
Weight per unit: 0.01 (lbs/each)

Price & Packaging

Minimum Order Quantity: 1
Unit: $1.69 (Each)
Carton: $8.45 (Per 5)

Resources

Images
: AGC10R - Large Image
: AGC10R - Large Image
: AGC10R - Large Image
: AGC10R - Small Image
: AGC10R - Large Image
Specifications Sheets
: AGC10R - Specification Sheet
Attachments
: AGC10R - Specification Sheet
Brochures
: AGC10R - Brochure
Other Links
: AGC10R - Other
: AGC10R - Other
: AGC10R - Other

Suggest Substitute Item

Help Improve Our Data

Edit Mode: Please login to suggest improvements for this item.

Close

Specifications

Thank you for your suggestions! We appreciate your assistance in improving our software. It helps us serve you even better!

Edit Mode: Please login to suggest improvements for this item.

Close

Help Improve Our Data

Features

Voltage Rating: 250 V ac
Material: Glass (Body);Brass( End Cap)
Terminal Type: Ferrule
Current Rating: 10 A
interrupt rating: 200 A @ 250 V ac;10000 A @ 125V ac
amperage rating: 10 A
connection: Ferrule End X Ferrule End

Dimensions and Weight

Diameter: 1/4 in;6.3 mm
Overall Length: 1-1/4 in;32 mm
Size: 1/4 In Diameter X 1-1/4 In Length

Descriptions

Description: 10A 250V 1/4X1-1/4 ROHS FA GLASS FUSE
Product Type: Fuse
Long Description: Fuse, Fast Acting Fuse Speed, 120/3.6k s Response Time, Ferrule End x Ferrule End Connection, 10 A, 250 V ac, Glass (Body);Brass( End Cap) Material, Ferrule Terminal, 1/4 in Diameter, 1-1/4 in Overall Length, 0.01 lb
Short Description: 10 A, 250 VAC, Fast Acting Fuse, ROHS, Glass
Features: Fast-acting, glass tube 1/4" x 1-1/4" ferrule fuse designed to UL 248-14 for overcurrent protection of electronic circuits. Install into a Bussmann Series fuse holder, block, or fuse clip, or purchase with available axial leads for thru-hole installation. Eaton's AGC fast-acting, glass tube 1/4" x 1-1/4" ferrule fuses are designed to UL 248-14 for overcurrent protection of electronic circuits. Order in cartridge fuse format and install into a Bussmann Series fuse holder, block, or fuse clip, or purchase w
extra long description: EFSE AGC-10-R BUSS SMALL DIMENSION
Special Features: Interrupt Rating 200 Amp at 250 Vac, 10000 Amp at 125 Vac, Material Glass Tube, Nickel Plated Brass Endcap, ROHS Compliant

Additional Information

Fuse Speed: Fast Acting
Connection Type: Ferrule End x Ferrule End
Standards Met: UL 248-14 Listed;CSA Certified;RoHS Compliant;CE Certified
package quantity: 5 CT
dimensions: 1.2500 IN X 0.2500 IN X 0.2500 IN
Response Time: 60 min at 135%, 120 sec at 200%

Manufacturer Information

Brand: Eaton Bussmann series
Manufacturers Part Number: AGC-10-R
GTIN: 00051712654982
UPC: 051712654982

Taxonomies, Classifications, and Categories

Category Description: GLASS FUSES (and ceramic)
Type: Fast-acting glass tube fuse

Packaging

Weight: 0.01 lb
Weight per each: 0.01
Carton: 5

Uses, Certifications, and Standards

Application: Electronic Circuits
standard: RoHS Compliant
