9669561623 - COR

9669561623 - CAT5E 24/4 Plenum Natural

Cables & Cords

  • $0.39 (Per Foot)
  • $0.39 (Per Foot)
  • $392.73 (Per 1,000 Feet)

Availablity: In Stock

Buy Now
QTY:
Feet
  • Help Improve Our Data
    Quick Specs
    Catalog Number
    9669561623
    Manufacturer
    Cables & Cords
    Manufacturer's Part Number
    9669561623
    Description
    CAT5E 24/4 Plenum Natural
    Twisted Pair Cable, Solid, 1000 FT Overall Length, 0.18 In Outside Diameter, 0.035 In Insulation Thickness, Copper Conductor Material, Fluorinated Ethylene Propylene Insulation Material, PVC Jacket Material, Natural, 4.3 DB/100 M @ 155 MHZ Attenuation, 5.6 NF/100 M Resistance, 0.019 LB/MFT
    Slang Terms

    Suggest a New Term
    Similar Brands

    Categories
    Twisted-Pair Cable - Pair Cable -Plenum Utp Cable  Mark as Incorrect
    Suggest a New Category
    Classification
    Electronic Cable
    UNSPSC
    26121600 - Electrical cable and accessories
    UPC/GTIN
    029892669560 / 00029892669560
    Weight per unit
    0.02 (lbs/ft)
    Price & Packaging
    Minimum Order Quantity
    Foot
    Unit
    $0.39 (Per Foot)
    Carton
    $392.73 (Per 1,000 Feet)
    Resources
    Images


    9669561623 - Small Image

    9669561623 - Large Image

    9669561623 - Large Image
    Specifications Sheets


    9669561623 - Specification Sheet
    Attachments


    9669561623 - Specification Sheet


    Suggest Substitute Item
    Help Improve Our Data
  • Help Improve Our Data
    Features
    Conductor Size
    24 AWG Solid
    Material, Color, and Finish
    Conductor Material
    Copper
    Insulation Material
    Fluorinated Ethylene Propylene
    Jacket Material
    PVC
    Color
    Natural
    Jacket Color
    NATURAL
    Insulation Color Code
    White/Blue with Blue, White/Orange with Orange, White/Green with Green, White/Brown with Brown
    Dimensions and Weight
    Overall Length
    1000 ft
    Length
    1000 ft
    Descriptions
    Product Type
    Twisted Pair Cable
    Description
    CAT5E 24/4 PLENUM NATURAL
    Long Description
    Twisted Pair Cable, Solid, 1000 ft Overall Length, 0.18 in Outside Diameter, 0.035 in Insulation Thickness, Copper Conductor Material, Fluorinated Ethylene Propylene Insulation Material, PVC Jacket Material, Natural, 4.3 db/100 m @ 155 MHz Attenuation, 5.6 nf/100 M Resistance, 0.019 lb/mft
    Short Description
    Twisted Pair Cable, Solid, 1000 ft, White
    Additional Information
    RoHS Compliant;ANSI/TIA/EIA-568B.2
    extra long description
    PLENUM TYPE; 1000 FT; SOLID BARE COPPER CONDUCTOR MATERIAL; UL 1666, CUL, ETL, CETL, NFPA 262 APPROVAL; REEL IN BOX STANDARD PACKAGE; FLUORINATED ETHYLENE PROPYLENE INSULATION MATERIAL; 24 AWG SOLID CONDUCTOR SIZE; LOW SMOKE PVC JACKET MATERIAL; NATURAL JACKET COLOR; 0.18 INCH CABLE OUTER DIAMETER; 5E CATEGORY; 0.035 INCH INSULATION THICKNESS; CMR, CMP, FT6 JACKET RATING; 5.6 NANOFARAD/100 M CAPACITANCE; 9.38 OHM/100 M DC RESISTANCE; 4 CONDUCTOR PAIR(S); 1 TO 350 MHZ OPERATING FREQUENCY; 4.3 DB/100 M AT 15
    Commodity Description
    PLENUM UNSHIELDED TWISTED-PAIR CBL
    Additional Information
    Solid/Strand
    Solid
    outside diameter
    0.18 in
    Insulation Thickness
    0.035 in
    Attenuation
    4.3 db/100 m @ 155 MHz
    Resistance
    5.6 nf/100 M
    Standards Met
    UL 1666;cUL Listed;ETL Listed;CETL Listed;NFPA 262
    Made in USA
    yes
    Cable Outer diameter
    0.18 INCH
    Operating Frequency
    1 to 350 MHz
    Number of Conductor Pairs
    4
    Capacitance
    5.6 Nanofarad/100 M
    Category
    5E
    DC Resistance
    9.38 OHM/100 M
    Jacket Rating
    CMR, CMP, FT6
    Manufacturer Information
    Brand
    Cables & Cords
    Manufacturers Part Number
    9669561623
    Model
    966956
    GTIN
    00029892669560
    UPC
    029892669560
    Taxonomies, Classifications, and Categories
    Category Description
    ELECTRONIC CABLE
    Type
    PLENUM
    Packaging
    Package Type
    Ribbon
    Weight
    0.019 lb/mft
    Standard Package
    Reel in Box
    Weight per foot
    0.02
    Carton
    1000
    Uses, Certifications, and Standards
    Application
    Gigabit Ethernet;ATM;Broad Band Video;Bi-Directional Transmission
    Approval
    UL 1666, CUL, ETL, CETL, NFPA 262
