THHN12S0LRD500 - THHN 12 Sol Red 500'

Copper

$95.38 (Per 500 Feet)
$0.19 (Per Foot)
$95.38 (Per 500 Feet)
$190.76 (Per 1,000 Feet)
$381.52 (Per 2,000 Feet)

In-Stock: 1,000 available locally (Hutchinson, KS) (change location)

Buy Now

QTY:

Feet

Overview
Reel Sizes
Specifications
Current Stock
Add-On Items
Alternate Items

Overview

Thank you for your suggestions! We appreciate your assistance in improving our software. It helps us serve you even better!

Edit Mode: Please login to suggest improvements for this item.

Help Improve Our Data

Quick Specs

Catalog Number: THHN12S0LRD500 Vendor Code COP
Manufacturer: Copper
Manufacturer's Part Number: 11589901
Description: THHN 12 Sol Red 500'
600 Volts. Copper Conductor. Thermoplastic Insulation/Nylon Sheath, Heat, Moisture, Gasoline and Oil Resistant Ii. Rated THHN and THWN. Also Rated Awm.
Slang Terms: Suggest a New Term
Categories: Copper Building Wire - THHN-T90-Sol (Solid) Mark as Incorrect
Suggest a New Category
Classification: Building Wire
UNSPSC: 26121517 - Copper wire
UPC/GTIN: 032886224201 / 00032886224201
Weight per unit: 0.023 (lbs/ft)

Price & Packaging

Minimum Order Quantity: 500 Feet
Unit: $0.19 (Per Foot)
Reel: $95.38 (Per 500 Feet)
Standard Packaging: $381.52 (Per 2,000 Feet)

Stock Availability

Hutchinson: 1,000 Feet (Check another store)
West Wichita: 12,500 Feet
All Stores: 969,000 Feet

Resources

Images
: Large Image - Large Image
: Small Image - Small Image
: THHN12S0LRD500 - Small Image
: THHN12S0LRD500 - Large Image
: THHN12S0LRD500 - Large Image
: THHN12S0LRD500 - Video
Attachments
: THHN12S0LRD500 - Specification Sheet
Other Links
: THHN12S0LRD500 - Other
: THHN12S0LRD500 - Other

Suggest Substitute Item

Help Improve Our Data

Edit Mode: Please login to suggest improvements for this item.

Reel Sizes

Specifications

Thank you for your suggestions! We appreciate your assistance in improving our software. It helps us serve you even better!

Edit Mode: Please login to suggest improvements for this item.

Help Improve Our Data

Features

Current Rating: 20 A
Number of Conductors: 1
Conductor Size: #12 AWG
Voltage Rating: 600 V

Material, Color, and Finish

Jacket Material: Nylon
Conductor Material: Annealed Copper
Color: Red (Insulation)
Insulation Material: PVC

Dimensions and Weight

Overall Length: 500 ft
Length: 500

Descriptions

Product Type: THHN Copper Building Wire
Features: Southwire(R) SIMpull THHN(R) copper conductors are made with soft drawn copper. Sizes 14 through 4/0 AWG use a combination-unilay stranding while 250 kcmil and larger sizes use a compressed copper stranding. The wire is covered with a tough heat and moisture resistant PVC insulation with an overall nylon jacket utilizing SIMpull(R) Technology. Available in black, white, red, blue, purple, green, yellow, orange, brown, and gray. Also available in striped configurations. Some colors are subject to economic o
Short Description: THHN Copper Building Wire, #12 AWG, Solid, Yellow, 500
Additional Information: Heat Resistant;Moisture Resistant
Description: THHN 12 SOL RED 500'
extra long description: SWC 11589901 THHN 12 Sol Cu Rd 500S
Long Description: 600 Volts. Copper Conductor. Thermoplastic Insulation/Nylon Sheath, Heat, Moisture, Gasoline and Oil Resistant II. Rated THHN and THWN. Also rated AWM.

Additional Information

Standards Met: RoHS Complaint;ASTM B3;ASTM B8;ASTM B787;Federal Specification A-A-59544;NFPA 70;NEMA WC-70;UL 83/758/1063/1581;UL Canada;UL US;CSA C22.2
Made in USA: yes
outside diameter: 119 mil
Insulation Thickness: 15 mil
Maximum Operating Temperature: +90 °C
media: Yes

Manufacturer Information

Brand: Copper
Manufacturers Part Number: 11589901
GTIN: 00032886224201
UPC: 032886224201

Taxonomies, Classifications, and Categories

Category Description: BUILDING WIRE
Type: THHN

Availability

minimum qty: 500

Packaging

Package Type: Spool
Weight: 23 lb/mft
Weight per foot: 0.023
Carton: 500
Package: 2000

Uses, Certifications, and Standards

Application: Building;Commercial;Industrial
